| MODEL |
ATS 1C |
ATS 2C |
ATS 3C |
ATS 4C |
ATS 5C |
| Channels |
64 |
128 |
192 |
256 |
320 |
| Power requirement(Kw) |
2.0 |
2.0 |
2.5 |
3.0 |
4.0 |
| Air compressor(HP) |
15 |
15 |
20 |
25 |
30 |
| Dimension(WxDxH) |
824 x
1,923 x
2,984 |
1,166 x
1,923 x
2,984 |
1,508 x
1,923 x
2,984 |
1,850 x
1,923 x
2,984 |
2,192 x
1,923 x
2,984 |
- Above specification is subject to change without prior notice for the technical improvement.
- Capacities may differ according to the kind of raw materials and its contamination ratio.
- Air compressor is not included with color sorter.
- CCD Model is available as ATS 1,ATS 2,ATS 3,ATS 4,ATS 5
|
|
|
|
|
|
 |
 |
|
