Technical details and dimensions
| MODEL |
S1 |
S1 PLUS |
S2 |
S3 |
S3 PLUS |
S4 |
S5 PLUS |
S6 |
S7 |
| Channels |
64 |
96 |
128 |
192 |
224 |
256 |
288 |
384 |
448 |
| Depth |
1,540 |
1,540 |
1,540 |
1,540 |
1,540 |
1,540 |
1,540 |
1,540 |
1,540 |
| Width |
852 |
1,086 |
1,212 |
1,500 |
1,824 |
2,004 |
2,004 |
2,472 |
2,796 |
| Height |
1,730 |
1,730 |
1,730 |
1,730 |
1,730 |
1,730 |
1,730 |
1,730 |
1,730 |
| Weight (Kgs) |
500 |
600 |
750 |
900 |
900 |
1,150 |
1,150 |
1,300 |
1,500 |
Air Compressor (HP)
|
5 |
5 |
7.5 |
10 |
10 |
20 |
20 |
35 |
35 |
- Specifications above is subject to change without prior notice due to technical improvements.
- Capacities may differ according to the kind of raw material and its contamination ratio.
- Air compressor is not included with color sorter.
- In case of Full color model, model name is S1C, S2C, S3C ,S4C ,S5C ,S6C,and S7C.
|
|
|
|
 |
 |
|
